Used Multi Process Pulse TIG Aluminum Welder AC DC TIG200P
Used Multi Process Pulse TIG Aluminum Welder AC DC TIG200P
This used machine has not been used by anyone, guaranteed to be 80% new, but has some minor scratches. If you don't mind this, this AC DC TIG welder would be a great choice for you, offered at a very affordable price.
Some minor scratches on the screen and traces of foam on the power cord.
For sale: Machines in 100% quality condition. Minor scratches due to transportation. Quality warranty period: 2 years.
Warm suggestion: Before using the AC DC TIG200P, it's recommended to adjust your machine using test parameters.
Pre-flow time: 0.5s
Starting current: 50A
Rising time: 0s
Welding current: 100A
Fall time: 0s
Ending current: 20A
AC frequency: 100HZ
Cleaning width: 30%
Welding material: 5mm aluminum plate
Tungsten electrode diameter: 2.4mm
Technical Parameters
The ARCCAPTAIN TIG200P AC/DC Pulse Tig Aluminum Welder offers excellent welding performance and versatility when working with aluminum. Thanks to its AC/DC capabilities, you'll have access to adjustable pulse characteristics and a wide range of welding modes. This creates an ideal environment for welding aluminum, making it an ideal choice for those working with this metal.
| Project Name | Unit | Value | ||
| Power voltage | VAC | AC110V±15% AC220V±15% | | |
| Input frequency | Hz | 50 | ||
| Rated input current | A | 33@TIG 35@MMA | ||
| Capacity of power supply | KVA | 6.0@TIG 7.5@MMA | ||
| Output current range (TIG) | A | 10~120(110 v) 10~200 (220v) | | |
| Output current range (MMA) | A | 10~110(110v) 10~160(220v) | | |
| Arc force range | A | 0~40 | ||
| Hot start current range | A | 0~80 | ||
| No-load voltage | V | 60 | ||
| Rated working voltage | V | 18@TIG 26.4@MMA | ||
| AC output frequency | Hz | 20~250 | ||
| AC balance | % | 20~60 | ||
| Background level | A | 10~200 | ||
| Pulse frequency | Hz | 0.5~200 (DC) 0.5~25(AC) | ||
| Pulse duty factor | % | 5~95 | ||
| Pre-flow time | S | 0~5 | ||
| Post-flow time | S | 0~15 | ||
| Rising time | S | 0~15 | ||
| Fall time | S | 0~15 | ||
| Remote control | - | Yes | ||
| Arc start mode | - | HF arc starter | ||
| Efficiency (%) | % | 80 | ||
| Duty cycle (%) | % | TIG: 200@25% - MMA: 160@25% | ||
| Power factor | - | 0.70 | ||
| Type of cooling | - | Air cooled | ||
| Working temperature range | °C | —10~+40 | ||
| Storage temperature range | °C | —25~+55 | ||
| Protection class | - | IP21S | ||
| Insulation class | - | B | ||
